The mid size model of the new ST-X Tall range – the ST-X5 Tall is rated at 5kW output, and approx 82% efficiency.

The ST-X5 Tall has a particularly large firebox for a 5kW model allowing a greater range of heat output and for larger logs to be burned.

Already EcoDesign compliant to meet 2022 ErP requirements. Minimal emmisions.

Constructed from a precision-welded thick steel body with cast iron door and thermo-refractory fire brick inner linings.

Many times cleaner than the required standard for 'DEFRA' exemption, it can legally be used anywhere in the UK including the strictest of smoke control zones.

Designed with simple, easy to operate user friendly controls.

Designed with a large viewing window for amazing views of the fire. The flame pattern with the advanced 'after-burner' system is quite unique.

The ST-X5 Tall is a multi-fuel stove able to efficiently burn wood logs or smokeless coal – the coal ashes will fall through the grate and into the ash can which easily lifts out when full.

The stove is ready to install, no assembly is required and comes complete with high temperature mitt/glove.

Finished in black high temperature paint which we source from the USA and with thermo-ceramic clear glass from the industry-leading Schott brand in Germany.

There is an air-wash system to help keep the glass clearer.

The ST-X5 Tall has a 5"(125mm) diameter top and rear flue outlet. Can be used with 5" diameter flue liner or twinwall flue.

Features

• Ecodesign 2022 Ready
• DEFRA Exempt / Approved for Smoke Control Areas
• Large viewing window
• 2-8kW operating range
• 81.8% efficiency
• Ultra-clean burning
• Low maintenance
• No delicate complex parts to go wrong
• Suitable for use on 12mm hearth
• Generous firebox size

Specifications

Heat output: 5kW

Height: 835mm

Width: 460mm

Depth: 370mm

Approx weight: 110 kg

Flue Size: 5" (125mm)

Internal Firebox Width - 340mm

Internal Firebox Depth - 255mm

Max Log Size - 12 inch (255mm)

Rear to centre of top flue - 120mm

Floor to centre of rear flue - 730mm

Distance to Combustibles 600mm to side walls / 700mm to Rear wall
